INTEGRIX® iX6 4.5-27X56 34 mm FFP LR/ELR Scope, M1 MRAD SKU iX645FM1
UTG
$2,399.97
(No reviews yet)
Write a Review
UTG
INTEGRIX® iX6 4.5-27X56 34 mm FFP LR/ELR Scope, M1 MRAD SKU iX645FM1
INTEGRIX® iX6 4.5-27X56 34 mm FFP LR/ELR Scope, M1 MRAD
The INTEGRIX® iX6 4.5-27X56 modernizes the 5-25X magnification to offer even greater versatility for long range engagements. Its large objective lens and 34 mm tube allow for maximum light and clarity in low light conditions and travel in your W/E adjustment. Available in two different precision reticles, the iX6 4.5-27X56 is a well-rounded optic for the advanced long-range marksman.
- Individually Centration Tested German and Japanese Glass Lenses, Concentric Tested Post Assembly
- Multi-Coated Lenses for Glare, Reflection, and Scratch Resistance
- Low Aberration Optimized Image Quality with Over a 92% Light Transmission
- Edge to Edge Sharpness, High Contrast, and High-Resolution Standard
- Reliable Adverse Temperature and Environmental Performance with -40° to 160° Fahrenheit Operational Range and IPX7 Waterproof Rating
- Rated, at Minimum, for .338 LAPUA Magnum
- Red and Green Reticle Illumination with 8 Brightness Intensity Settings
- 12 Hour Automatic Shutoff
- Side Adjustable Parallax Turret Smoothly and Accurately Adjusts from 30 Yards / 27.4 m to Infinity
- Intuitive Lockable and Zero Resettable Windage and Elevation Turrets, Serrated and Oversized for Glove Use
- Elevation Turret Equipped with Zero Stop
- Serrated Power Ring and Rear Adjustable Eyepiece Diopter
- Make Transitioning Across Magnification Range Effortless with Included Oversized Throw Lever
ETCHED GLASS M1 MRAD RETICLE
TRIED AND TRUE TRADITIONALIST
A tried-and-true MRAD Reticle made for true marksmen looking to challenge themselves at ranges most could not reach.
RETICLE HOLDOVERS
Your reticle features 12 Mils of holdovers broken into 0.2 Mil increments for exact shot placement. Vertical and horizontal stadia feature 1-2 Mils of 0.1 Mil increments for finer measurements.
WIND HOLDS
The main horizontal stadia include 24 Mils of wind holds with 2 Mils of 0.1 Mil increments on both sides. Do not be afraid to have fun in the wind with up to 4.5 Mils of wind holds.
QUICK RANGING SYSTEM
A quick-ranging system is built into the M1 reticle, able to range an 18-inch width target from 400 to 1,000 yards.
RETICLE BREAKDOWN
| UNIT | A | D | E | F | G | H | I |
| MIL | 24 | 0.05 | 0.1 | 0.1 | 0.15 | 0.4 | 0.03 |
| UNIT | J | K | L | M | N | O | P |
| MIL | 12 | 0.2 | 0.1 | 9 | 0.4 | 0.2 | 0.5 |
| UNIT | Q | R | S | T | U | V | W |
| MIL | 0.05 | 1.5 | 1 | 0.1 | 0.2 | 0.5 | 1 |
| UNIT | B |
| INCH @ 400 YARDS | 18 |
| UNIT | C |
| INCH @ 1000 YARDS | 18 |
| Auto Shutoff | 12 hrs |
|---|---|
| Ballistic Drop Compensation | No |
| Battery Loading | Left Side Turret |
| Battery Type | CR2032 3V |
| Brightness Mode(s) | Manual |
| Brightness Settings | 8 |
| Caliber Rating | .338 Lapua Magnum |
| Click Value | 0.1 MRAD |
| Diopter Adjustment | -3D to +2D |
| Diopter Type | Friction Secured |
| Elevation Travel | Up 19 MRAD / Down 13.5 MRAD |
| Elevation Travel (Total) | 32.5 MRAD |
| Exit Pupil | Low Power: 2.1 mm / High Power: 11 mm |
| Eye Relief | 3.94 in (100 mm) |
| Field of View (Angular FOV) | Low Power: 4.8° / High Power: 0.8° |
| Field of View (Linear FOV @ 100 m) | Low Power: 8.4 m / High Power: 1.4 m |
| Field of View (Linear FOV @ 100 yds) | Low Power: 25.1′ / High Power: 4.2′ |
| Focal Plane | FFP (First Focal Plane) |
| Illuminated | Yes |
| Illumination Toggle Type | Button |
| Light Transmission | 92% |
| Magnification Max. | 27X |
| Magnification Min. | 4.5X |
| Materials | 6061-T6 Aluminum |
| Parallax | 30 yds (27.4 m) - Infinity |
| Parallax Control | Left Side Adjustable Turret |
| Patent | US PAT. 12001007 / US PAT. D979005 / US PAT. D989909 / US PAT. D989910 |
| Range Estimation | Yes |
| Reticle | M1 MRAD |
| Reticle Color | Red and Green |
| Reticle Type | Etched Glass |
| Surface Finish | Anodized |
| Temperature Operating Range | -40⁰F to +160⁰F (-40⁰C to +71⁰C) |
| Travel Per Revolution | 10 MRAD |
| Waterproof Rating | IPX7 |
| Weight | 33.7 oz (956 g) |
| Windage Travel | Right 5 MRAD / Left 5 MRAD |
| Windage Travel (Total) | 10 MRAD |
| Elevation Turret Diameter | 1.65 in (42 mm) |
|---|---|
| Elevation Turret Height | 1.92 in (49 mm) |
| Eyepiece Diameter | 1.81 in (46 mm) |
| Front Mounting Space | 1.97 in (50 mm) |
| Length | 14.13 in (359 mm) |
| Objective Diameter | 2.56 in (65 mm) |
| Objective Lens Diameter | 56 mm |
| Objective Tube Length | 4.96 in (126 mm) |
| Ocular Tube Length | 3.46 in (88 mm) |
| Parallax/Illumination Turret Diameter | 1.50 in (38 mm) |
| Parallax/Illumination Turret Height | 2.05 in (52 mm) |
| Rear Mounting Space | 1.97 in (50 mm) |
| Total Mounting Space | 5.71 in (145 mm) |
| Tube Diameter | 34 mm |
| Windage Turret Diameter | 1.65 in (42 mm) |
| Windage Turret Height | 1.88 in (48 mm) |
| # | IMAGE | DESCRIPTION | QUANTITY |
|---|---|---|---|
| 1 |  |
1.5 mm Hex Wrench | 1 |
| 2 |  |
2 mm Hex Wrench | 1 |
| 3 |  |
CR2032 3V Battery | 1 |
| 4 |  |
Flip-open Lens Caps | 1 |
| 5 |  |
Throw Lever | 1 |
| 6 |  |
Sunshade | 1 |
| 7 |  |
Cleaning Cloth | 1 |
| 8 |  |
User Manual | 1 |
LEAPERS® LIFETIME WARRANTY
Leapers, Inc. warrants that all products conform to published specifications and are free from defects in material and workmanship. Leapers, Inc. will repair or replace, at our discretion, a defective product for the duration of the product’s lifespan. In the event of a product being discontinued, credit for the product’s MSRP may be offered.
